Concrete Pump Truck

Langfang Nianpeng Mechanical Equipment Processing Co., Ltd. is one of the most reliable manufacturers and suppliers of concrete pump truck in China. If you're going to buy high quality concrete pump truck, welcome to get pricelist and quotation from our factory. For price consultation, contact us.



Basic Info.

---

---

Model NO.	Diesel Concrete Conveying Pump	Type	Diesel Concrete Conveying Pump
Shotcrete Type	Wet	Machining Process	Hydraulic
Structure	Piston Type	Productivity	52m³/H
Feeding Height	1400mm	Vibrating Amplitude	0
Certification	ISO9001: 2000, CE	Condition	New
Color	Blue	Gross Weight	4800kg
Maximum Theoretical Discharge	52m³/H	Concrete Conveyor Pressure	10MPa
Maximum Theoretical Pumping Distance	Vertical 180/Horizontal 500m	Diesel Engine Power	92kw
Hydraulic Tank Volume	180L	Specification	3700*1700*1700
Trademark	nianpeng	Origin	Langfang Hebei China



Packaging & Delivery

Package Size	4500.00cm * 1850.00cm * 1950.00cm
Package Gross Weight	8474310000



Product Description



Imported hydraulic oil pump, ltaly Manuli hydraulic tubing, the main electricalcomponents using Japan Omron, Mitsubishi brand electrical appliances, cylinderusing imported seal, with high and low pressure switching, the main cylinder, concretecylinder, hopper, S valve produced by well-known domestic manufacturers, the newgeneration of pumps use electronic proportional control technology, the pumpingdisplacement is stepless adjustment, the new generation of pumps use streamlinedarc, more beautiful and durable.



Equipment Parameters



Model	Unit	NPJ30.6.52RS	NPJ40.8.62RS	NPJ50.10.92RS	NPJ50.13.92RS
Maximum theoretical discharge	m³/h	30	40	52	65/41
Concrete conveyor pressure	mpa	6	8	10	13/7
Maximum theoretical pumping distance	m	Vertical 50/ horizontal 200	Vertical 80/ horizontal 280	Vertical 180/horizontal 500	Vertical 280/horizontal 1000
Maximum theoretical discharge		S-valve	S-valve	S-valve	S-valve
Conveying cylinder specification	mm	Φ180x500	Φ200x977	Φ200x977	Φ200x1600
Cylinder specification	mm	Φ90x55x500	Φ90x65x800	Φ100x70x800	Φ125x80x1600
Hopper volume	m³	0.5	0.7	0.7	0.8
Diesel engine power	kw	52	62	92	130
Hydraulic tank volume	L	170	180	180	500
Maximum particle of aggregate	kw	30	40	40	40
Gross weight	kgs	2000	4500	4800	6300
Equipment size	mm	3700x1700x1700	4500x1850x1950	4500x1850x1950	6300x2100x2250



Application Scenarios





FAO

01. WHAT IS YOUR TERMS OF PACKING? A: Generaly, we pack our goods in nude package and loaded into contalner. if necesany, we can packit into plywood box
02. WHATIS YOUR TERMS OF PAYMENT? A: T/T 30% as deposit,and 70% befcre deliveny. Well show you the photos ofthe products and packages before you pay thebalance.

03. WHATIS YOUR TERMS OF DELIVERY? A:EXW,.FOB,CFR, CIE.
04. HOW ABOUT YOUR DELIVERY TIME? A: Genery,it wl take 10-20 days afer recelving your advance paymen.The specifc deiveny time depends on the tiems and
the quantity of your order.

05, CAN YOU PRODUCE ACCORDING TO THE SAMPLEs?A: Yes, we can produce by your samples or lechnicaldrawings. We can build the molds and fixtures

O6. DO YOU TESTALL YOUR GOODS BEFORE DELIVERY? A: Yes, we have 100% test before delivery.
07. HOW DO YOU MAKE OUR BUSINESS LONG.TERM AND GOOD RELATIONSHIP? A: 1.We keep good qualy and compettive pice to ensure our customers benefit2.We respect every customer as our friend and we sincerely do business and make friends with them.no mater where they come from.









































Hot Tags: concrete pump truck, China concrete pump truck manufacturers, suppliers, factory
